Metallized Dip Capacitors

Metallized Polyester capacitor - MPT Capacitors are wound with Metallized polyester film as dielectric and copper clad steel wire and epoxy coating. Features1) Miniature 5mm piitch2 Automotive grade3) Temperature Range -55C to +105C4) Self healing properties5) Non - inductive construction 6) High Moisture resistance & good solderability Application1) Suitable for blocking, coupling, de-coupling, filtering and other general-purpose applications2) Widely used in filter and low pulse circuits3) High stability Automotive application Tech Specs - VALUE 1.0uF 10% 1) Electrodes - Aluminum Metallization2) Dielectric - Polyester Film (Polyethylene terephthalate3) Terminals - Tin coated copper clad steel wires 4) Test voltage - 1.6 times Vr = 160VDC for 2 seconds 5) Insulation Resistance -Greater than 10,000 M6) Dissipation Factor 0.008 at 1Khz and 25C

MPT - Metallized Polyester Capacitors - 100VDC to 630VDC

MPP - Metallized Polypropylene Capacitors - 100VDC to 1000VDC

MPM - High Voltage Metallized Polypropylene Capacitors - 1000VDC to 2000VDC

X2 Capacitors - MPX 300VAC (0.01uF - 1uF)

CDI Auto capacitor Dischage Ignition Capacitor

Metallized Polypropylene Fan Regulator Capacitors - MKP11 (1uF - 4.3uF in 250VAC)

Metallized Polyester Fan Regulator Capacitors - MKT111 (1uF - 4.3uF in 250VAC)

Safety Fan Regulator Capacitors - MKT11S (1uF - 4.3uF in 250VAC)
